PTS 1000 to PTS 20,000: How to Choose the Right Master Filter Size for Your Business
Share
Choosing a master filtration system isn't a one-size-fits-all decision. The right model depends on how much water your building uses, how poor your incoming water quality is, and whether you're filtering a single point of use or an entire property. Panaxy's PVDF Plus master filtration line comes in five sizes — from PTS 1000 up to PTS 20,000 — and picking the right one makes a real difference in maintenance frequency and long-term performance.
What the PVDF Plus System Does
Before comparing sizes, it helps to understand what the whole PVDF Plus line has in common:
- Industrial-grade membrane: PVDF Plus (double layer + lining)
- Micron rating: 0.01 μm — fine enough to capture microscopic particles
- Filters and reduces: Particles, dirt, rust, and cysts
- Halal certified (Cert No. 6 047-05/2023)
- Membrane lifespan: 2 years
- Designed for commercial use, including restaurants (actual performance depends on incoming water quality and usage)
Every model shares this same filtration performance and Halal certification. What differs between models is capacity — how much water volume each is designed to handle before the membrane needs washing.
Comparing the PTS Model Sizes
| Model | Suggested Membrane Washing Period | Best Suited For |
|---|---|---|
| PTS 1000 | Weekly | End-point use only — not recommended for whole-building filtration |
| PTS 3000 | Monthly | Smaller properties or lighter water usage |
| PTS 5000 | Every 3 months | Mid-sized properties or moderate commercial usage |
| PTS 8000 | Every 5 months | Larger properties, busier commercial kitchens |
| PTS 10,000 | Every 6 months | High-volume buildings, larger restaurants, or properties with heavy daily water usage |
Note: actual washing frequency depends on incoming water quality and actual usage. Buildings with particularly poor water quality (high sediment, rust, or turbidity) may need to wash the membrane more often than the general guide above, regardless of model size.
Important: PTS 1000 Is Not a Whole-Building Solution
It's worth calling out specifically: PTS 1000 is intended for end-point use only — such as filtering water for a single application — and is not recommended as a whole-building master filter. If you're looking to protect an entire property's water supply, you'll need to size up to PTS 5000 or above depending on your usage volume.
How to Estimate the Right Size for Your Property
A few practical questions can help narrow down the right model:
1. Is this for one specific application, or the whole building?
If it's a single point of use, PTS 1000 may be sufficient. For whole-building coverage, start from PTS 5000 upward.
2. How much daily water volume does your property use?
Restaurants, cafés with multiple stations, or buildings with many occupants will move through more water daily, generally pointing toward PTS 5000, 8000, or 10,000.
3. How would you rate your incoming water quality?
If your building is older, has known rust or sediment issues, or you've experienced frequent point-of-use filter clogging, lean toward a larger model with a longer buffer between washes — or plan for more frequent washing regardless of size.
4. Is this for a restaurant or commercial food operation?
The PVDF Plus line is designed to support commercial use, including restaurants, but higher-traffic kitchens should generally size up to reduce how often the membrane needs attention.
Technical Specifications (All Models)
- Material: PVDF+ Fiber
- Structure: PP head & filter housing + PVDF+
-
Operating temperature: 5–45°C
Why Getting the Size Right Matters
Undersizing a master filter for your actual water usage means more frequent membrane washing than necessary, more hands-on maintenance, and potentially reduced flow rate as the membrane approaches capacity between washes. Oversizing isn't usually harmful, but it may mean paying for more capacity than your property actually needs.
Getting the sizing right the first time — based on realistic usage and water quality — is the most cost-effective way to install a master filtration system that fits your building for the long term.
Final Thoughts
Whether you're filtering a single point of use or protecting an entire restaurant's water supply, Panaxy's PVDF Plus line — from PTS 1000 to PTS 10,000 — offers Halal-certified, industrial-grade filtration sized to match your actual needs. Choosing correctly upfront means longer intervals between maintenance and more reliable protection for everything downstream.
Not sure which model fits your property? Get a sizing recommendation at panaxyfiltration.com.
FAQ
Can I use PTS 1000 for my whole building?
No — PTS 1000 is intended for end-point use only and is not recommended as a whole-building master filter. For whole-building coverage, consider PTS 3000 or larger.
Do all PTS models filter to the same standard?
Yes, all models share the same PVDF Plus membrane, 0.01 micron rating, and turbidity performance (up to 1,000 NTU incoming, ≤0.1 NTU output). The difference between models is capacity and washing frequency.
How do I know if I need to wash the membrane more often than suggested?
If your incoming water quality is particularly poor or your usage is higher than typical for your model size, plan to wash more frequently than the standard guide suggests.
